ASTM D7400 Downhole Seismic Testing for Shear Wave Velocity
The Downhole Seismic Testing can be performed using the standard test method ASTM D7400. Several acceptable devices can be used to generate a high-quality P or SV source wave or both SH source waves. Several types of commercially available receivers and recording systems can also be used to conduct an acceptable downhole survey.
TRUSTED BY
Precision-driven testing for dimensional accuracy and compliance
- Overview
- Scope, Applications, and Benefits
- Test Process
- Specifications
- Instrumentation
- Results and Deliverables
Overview
ASTM D7400 describes a standard test method for performing downhole seismic testing to determine the interval velocities of compression (P) and shear (S) waves in subsurface soils and rock. Several acceptable devices can be used to generate high-quality P or SV source waves, as well as SH source waves, making this method highly versatile.
This test method is widely used in geotechnical engineering to derive critical elastic constants such as Poisson’s ratio, shear modulus, bulk modulus, and Young’s modulus. It supports foundation design, site characterization, and seismic hazard assessments across construction, civil engineering, and environmental sectors.
Scope, Applications, and Benefits
Scope
ASTM D7400 covers the determination of:
- Interval velocities from P-wave and S-wave arrival times
- Geotechnical elastic constants (shear modulus, bulk modulus, Young’s modulus, Poisson’s ratio)
- SV (vertically polarized) and SH (horizontally polarized) shear wave velocities
- Subsurface soil and rock dynamic properties
Applications
- Geotechnical site characterization for construction projects
- Seismic hazard and liquefaction assessment
- Foundation design and soil stiffness evaluation
- Environmental site investigations
- Infrastructure projects including bridges, dams, and tunnels
Benefits
- Provides in-situ, non-destructive subsurface data
- Directly yields elastic constants for engineering design
- Supports multiple wave types (P, SV, SH) in one test
- Delivers repeatable, standardized results across sites
- Reduces reliance on laboratory-only soil testing
Test Process
Borehole Preparation
Drill a borehole to the required depth, case it with PVC or aluminum casing, and grout in place to ensure good acoustic coupling.
1Receiver Deployment
Push or lower seismic receivers to the desired test depth; align horizontal transducer axes with the shear beam direction.
2Downhole Testing
Activate the energy source, record P-wave and S-wave traces for all receivers, and repeat 3–5 times to improve signal-to-noise ratio.
3Data Analysis
Calculate interval velocities from arrival time differences; derive elastic constants using P and S wave velocity data.
4Technical Specifications
| Parameter | Details |
|---|---|
| Standard | ASTM D7400 |
| Test Principle | Measurement of seismic wave travel times in a borehole |
| Applicable Materials | Soils and rock formations |
| Borehole Diameter | Not exceeding 175 mm (7.0 in.) |
| Shear Beam Length | 2.4 m (8 ft.) |
| Shear Beam Width | 150 mm (6 in.) |
| Hammer Mass | 1 to 15 kg |
| Measured Outputs | P-wave velocity, S-wave velocity, elastic constants |
| Data Units | SI units and inch-pound units |
Instrumentation Used for Testing
- Seismic energy source (hammer and shear beam)
- Downhole seismic receivers (uniaxial, biaxial, or triaxial)
- PVC or aluminum borehole casing
- Grout pump and grouting materials
- Seismic recording system with digital storage
- Potentiometers and timing verification equipment
Results and Deliverables
- P-wave and S-wave velocity profiles vs. depth
- Shear modulus, bulk modulus, and Young’s modulus profiles
- Poisson’s ratio values
- Interval velocity plots
- Site-specific elastic constant reports for engineering design
- Input data for seismic hazard and liquefaction analysis
Why Choose Infinita Lab for ASTM D7400?
At the core of this breadth is our network of 2,000+ accredited labs in the USA, offering access to over 10,000 test types. From advanced metrology (SEM, TEM, RBS, XPS) to mechanical, dielectric, environmental, and standardized ASTM/ISO testing, we give clients unmatched flexibility, specialization, and scale. You’re not limited by geography, facility, or methodology—Infinita connects you to the right testing, every time.
Looking for a trusted partner to achieve your research goals? Schedule a meeting with us, send us a request, or call us at (888) 878-3090 to learn more about our services and how we can support you. Request a Quote
Frequently Asked Questions
P-waves (compression waves) travel through soil by alternating compression and expansion. S-waves (shear waves) move material perpendicular to the wave direction. Both wave types are measured to calculate different geotechnical elastic constants.
ASTM D7400 does not set a strict depth limit; testing continues until the maximum borehole depth is reached. Practically, tests are conducted at intervals no greater than 1.5 m (5 ft.) apart.
Grouting ensures good acoustic coupling between the casing and the borehole wall, minimizing signal noise caused by gaps or loose material that could distort wave arrival times.
A dry borehole is preferred to avoid signal noise from waves traveling through the water column. Water-filled boreholes are permissible but may reduce data quality.
Receivers are repositioned at intervals of 0.5 to 1.5 m throughout the borehole depth, with all depths recorded. The number of test points depends on the total depth and required resolution of the velocity profile.
