MIL-STD-202 Method 107 Thermal Shock Testing for Electronic Components
MIL-STD 202 are standards developed by the US Department of Defence to test the resistance of electrical and electronic components against various environmental factors. Method 107 under MIL-STD 202 assesses the resistance of electrical and electronic components against extreme temperatures such as when any component is taken outside from a heated room in Arctic areas.
TRUSTED BY
Precision-driven testing for dimensional accuracy and compliance
- Overview
- Scope, Applications, and Benefits
- Test Process
- Specifications
- Instrumentation
- Results and Deliverables
Overview
MIL-STD-202 Method 107 thermal shock test is designed to test the ability of the electrical and electronic components to withstand extreme temperature transitions from one set of high and low temperature conditions to another. As part of the overall MIL-STD-202 environmental test criteria for electronic and electrical component parts, Method 107 of the test evaluates the components for their ability to withstand the rigors of repeated rapid thermal shock tests, simulating the conditions experienced during transportation between extreme temperature conditions, cold temperature operations, and exposure to thermally extreme conditions.
Scope, Applications, and Benefits
Scope
MIL-STD-202 Method 107 exposes electrical and electronic components to continuous cycles of extreme high and low temperatures within calibrated air or liquid bath environmental chambers, evaluating thermal shock-induced dimensional changes, physical damage, and permanent functional alterations across a minimum of five defined test cycles.
MIL-STD-202 Method 107 thermal shock testing evaluates:
- Tolerance of electrical and electronic components to repeated extreme temperature transitions
- Dimensional stability and physical integrity following rapid high-to-low temperature cycling
- Functional performance changes resulting from thermal shock-induced material stress
- Resilience of component materials, seals, and interfaces under repeated thermal shock exposure
- Compliance against MIL-STD-202 Method 107 thermal shock qualification requirements
Applications
- Electrical and electronic component parts requiring MIL-STD-202 environmental qualification
- Military and defense electronic assemblies are subjected to extreme thermal field environments
- Aerospace and airborne electronic components are experiencing rapid temperature transitions
- Components are transported between heated and frigid environments during military logistics operations
- Commercial electronic components requiring MIL-STD-202 thermal shock qualification for defense procurement
Benefits
- Supports MIL-STD-202 Method 107 qualification and defense procurement compliance
- Provides certified thermal shock test data for component qualification submittals
- Identifies thermal stress vulnerabilities in electronic components before field deployment
- Delivers traceable test documentation aligned with MIL-STD-202 qualification requirements
- Reduces program risk by detecting thermal shock failure modes early in the component qualification cycle
Test Process
Sample Preparation
Components are inspected, baseline-tested, and positioned within the environmental chamber to ensure maximum exposure to heated or cooled air or liquid per MIL-STD-202 Method 107 requirements.
1Thermal Shock Exposure
Specimens are subjected to continuous cycles of extreme high and low temperature conditions for a minimum of five cycles, with effective transition time not exceeding five minutes between temperature extremes.
2Performance Monitoring
Throughout thermal shock cycling, specimens are monitored for physical damage, dimensional changes, and any visible deterioration resulting from repeated extreme temperature transitions.
3Post-Exposure Evaluation
Following completion of the defined test cycles, specimens undergo full functional testing and physical inspection against pre-test baseline data to determine test compliance result.
4Technical Specifications
| Parameter | Details |
|---|---|
| Applicable Components | Electrical and electronic component parts requiring MIL-STD-202 Method 107 thermal shock qualification |
| Test Medium | Air or liquid bath environmental chambers per MIL-STD-202 Method 107 specified test conditions |
| Number of Cycles | Minimum five continuous high-to-low temperature cycles per MIL-STD-202 Method 107 requirements |
| Transition Time | Effective transition time between temperature extremes not exceeding five minutes |
| Specimen Conditioning | Pre-test functional baseline testing and maximum thermal exposure positioning setup |
| Measured Outputs | Dimensional stability data, functional performance observations, physical damage assessment, and test compliance result |
Instrumentation Used for Testing
- Calibrated air or liquid bath thermal shock environmental chambers
- Precision temperature sensors for real-time thermal profile monitoring
- Automated or controlled specimen transfer system for rapid temperature transition
- Environmental conditioning equipment for pre-test component stabilization
- Functional test equipment for pre- and post-exposure performance evaluation
- Data acquisition and test event logging system
Results and Deliverables
- Thermal shock exposure records, including temperature extremes, cycle count, and transition time data
- Pre- and post-exposure functional performance comparison data for all tested components
- Physical damage and dimensional stability observations following thermal shock cycles
- Test compliance result assessed against MIL-STD-202 Method 107 acceptance criteria
- MIL-STD-202 Method 107 Compliance Report
Why Choose Infinita Lab for MIL-STD-202 Method 107 ?
Infinita Lab is a trusted USA-based testing laboratory offering MIL-STD-202 Method 107 testing services across an extensive network of accredited facilities across the USA.
Infinita Lab is built to serve the full spectrum of modern testing needs—across industries, materials, and methodologies. Our advanced equipment and expert professionals deliver highly accurate and prompt test results, helping businesses achieve quality compliance and product reliability.
Looking for a trusted partner to achieve your research goals? Schedule a meeting with us, send us a request, or call us at (888) 878-3090 to learn more about our services and how we can support you. Request a Quote
Frequently Asked Questions
The thermal shock tests according to MIL-STD-202 method 107 are used to determine the level of tolerance that electrical or electronic components can withstand to sudden extreme temperature changes.
The MIL-STD-202 method 107 specifies that there should be at least five continuous high-to-low temperature cycles, with the effective time to reach the extremes not to exceed five minutes, to apply thermal shock stress to the components tested.
The MIL-STD-202 Method 107 thermal shock tests are performed using air- or liquid-bath environmental chambers. In cases where liquid baths are employed, only liquids approved under MIL-STD-202 Method 107 are used.
Method 107 is used to detect dimensional changes, physical cracking, seal/interface failure, coating delamination, and permanent functional alterations in electrical and electronic components resulting from repeated rapid thermal expansion and contraction stress from extreme temperature transitions.
MIL-STD-202 Method 107 thermal shock qualification is frequently a specification requirement for U.S. DoD procurement programs and defense prime contracts involving electrical and electronic component parts. Please verify these requirements against your applicable specification and contract documents.
