ASTM D6289-13 Measuring Mold Shrinkage and Post-Shrinkage of Thermosetting Plastics
ASTM D6289-13 test method is used to measure the molding shrinkage of thermosetting plastics. Molding shrinkage is the difference in dimensions between the molding and the mold cavity in which it was molded.
TRUSTED BY
Precision-driven testing for dimensional accuracy and compliance
- Overview
- Scope, Applications, and Benefits
- Test Process
- Specifications
- Instrumentation
- Results and Deliverables
Overview
ASTM D6289-13 is a standardized test method used to determine mold shrinkage and post-shrinkage behavior in thermosetting plastics. It evaluates dimensional changes that occur during molding and after cooling, providing critical insights into material stability and processing performance.
This test is essential for manufacturers and engineers working with thermoset materials, as shrinkage directly impacts part accuracy, tolerance control, and final product quality. By understanding both in-mold and post-mold shrinkage, users can optimize tooling design and processing conditions effectively.
Scope, Applications, and Benefits
Scope
ASTM D6289-13 defines procedures for measuring linear mold shrinkage and subsequent post-shrinkage of thermosetting plastics under controlled conditions. It applies to materials processed by compression, transfer, or injection molding and ensures reproducibility and comparability of shrinkage data.
Key scope elements include:
- Measurement of dimensional change between mold cavity and molded specimen
- Evaluation of post-shrinkage over a specified time period
- Applicability to reinforced and unreinforced thermosetting plastics
- Use of standardized mold geometries and conditioning environments
- Guidance for reporting shrinkage values in linear dimensions
Applications
- Tooling and mold design optimization
- Quality control in thermoset plastic production
- Material comparison and selection
- Dimensional stability analysis
- Process parameter optimization
- Automotive and electrical component manufacturing
- Aerospace composite component evaluation
- Precision molded part development
Benefits
- Ensures accurate dimensional control of molded parts
- Helps predict material behavior after molding
- Supports improved mold design and tolerance setting
- Enhances product consistency and reliability
- Reduces rejection rates and rework costs
- Provides standardized data for material comparison
- Improves process efficiency and optimization
Test Process
Specimen Molding
Thermosetting plastic is molded into a standardized cavity under controlled temperature and pressure conditions.
1Initial Measurement
Dimensions of the molded specimen are measured immediately after removal from the mold.
2Conditioning Period
Specimen is conditioned for a specified time to allow post-shrinkage to occur under controlled environment.
3Final Measurement
Dimensions are re-measured to calculate mold shrinkage and post-shrinkage values.
4Technical Specifications
| Parameter | Details |
|---|---|
| Material Type | Thermosetting plastics (reinforced/unreinforced) Measurement Type: Linear dimensional shrinkage |
| Units | Typically mm/mm or percentage (%) |
| Molding Methods | Compression, transfer, injection molding |
| Conditioning Time | Defined per material specification |
| Temperature Control | Strict molding and conditioning temperatures required |
| Specimen Geometry | Standard mold cavity dimensions specified |
Instrumentation Used for Testing
- Precision mold with standardized cavity
- Vernier caliper or micrometer
- Conditioning chamber
- Compression/injection molding machine
- Temperature control system
- Measuring gauges
Results and Deliverables
- Mold shrinkage values
- Post-shrinkage values
- Dimensional stability analysis
- Test report with conditions and observations
- Compliance with ASTM D6289-13
- Material performance comparison data
Why Choose Infinita Lab for ASTM D6289-13?
Infinita Lab is a leading provider of ASTM D6289-13 and streamlined material testing services, addressing the critical challenges faced by emerging businesses and established enterprises. With access to a vast network of over 2,000+ accredited partner labs across the United States, Infinita Lab ensures rapid, accurate, and cost-effective testing solutions. The company’s unique value proposition includes comprehensive project management, confidentiality assurance, and seamless communication through a Single Point of Contact (SPOC) model. By eliminating inefficiencies in traditional material testing workflows, Infinita Lab accelerates research and development (R&D) processes.
Looking for a trusted partner to achieve your research goals? Schedule a meeting with us, send us a request, or call us at (888) 878-3090 to learn more about our services and how we can support you. Request a Quote
Frequently Asked Questions
ASTM D6289-13 provides precise shrinkage and post-shrinkage values, enabling engineers to compensate for dimensional changes during mold design. This ensures final molded parts meet tight tolerances, reduces trial-and-error iterations, and significantly improves manufacturing efficiency and dimensional accuracy.
Measuring both mold shrinkage and post-shrinkage ensures a complete understanding of dimensional changes. While mold shrinkage occurs during cooling, post-shrinkage reflects long-term stability, helping predict final dimensions and ensuring product reliability in real-world applications.
Curing temperature, pressure, and time directly impact polymer crosslinking and density. Improper curing can lead to uneven shrinkage or internal stresses, while optimized conditions ensure uniform dimensional stability and minimize variations between molded components.
In high-precision applications, even minor dimensional deviations can cause functional failures. ASTM D6289-13 ensures accurate shrinkage data, enabling manufacturers to maintain strict tolerances required in industries like aerospace, electrical insulation, and advanced composites manufacturing.
Reinforcements such as glass fibers restrict polymer contraction, reducing overall shrinkage. However, they may introduce anisotropic behavior, meaning shrinkage varies by direction, which must be carefully considered during mold design and product development.
