ASTM D1062 Cleavage Strength of Metal-to-Metal Adhesive Bonds

The ASTM D1062 test method includes the evaluation of adhesive bond’s comparative cleavage qualities when evaluated on standard form metal specimens under defined preparation and testing conditions. The performance of specimens evaluated using this method is expressed in SI units.

Talk to an Expert

ASTM D1062 Cleavage Strength of Metal-to-Metal Adhesive Bonds

TRUSTED BY

Precision-driven testing for dimensional accuracy and compliance

Overview
Scope, Applications, and Benefits
Test Process
Specifications
Instrumentation
Results and Deliverables

Overview

ASTM D-1062 Cleavage Strength Testing is a standardized test method for measuring the cleavage strength of adhesive bonds between two metals under specified tensile cleavage loading conditions. The ASTM D-1062 standard outlines test methods for measuring the resistance of adhesive bonds between two metals to cleavage failure, providing valuable information for materials engineers, adhesive material chemists, and manufacturers on the cleavage strength of these bonds.

Scope, Applications, and Benefits

Scope

ASTM D 1062 is used to determine the cleavage strength of adhesive bonds between metals by subjecting a joint specimen of a specific metal to a specified tensile cleavage force and measuring the maximum cleavage force at which the adhesive bond fails.

ASTM D 1062 cleavage strength testing evaluates:

Cleavage strength of metal-to-metal adhesive bond joints under defined tensile loading
Resistance of structural adhesive systems to cleavage failure at metal substrate interfaces
Comparative cleavage performance of adhesive formulations on defined metal substrate systems
Effect of adhesive thickness, cure conditions, and surface preparation on cleavage strength
Compliance against defined minimum cleavage strength requirements for metal adhesive joints

Applications

Structural adhesive systems for metal-to-metal bonding in aerospace and defense assemblies
Automotive body panel and structural component metal adhesive joint applications
Industrial equipment and machinery metal adhesive bond cleavage verification programs
Electronic and electrical enclosure metal assembly adhesive joint assessment
Adhesive formulators and material suppliers requiring ASTM D 1062 cleavage strength data

Benefits

Provides reliable cleavage strength data for metal-to-metal adhesive joint design
Supports adhesive specification compliance and supplier verification programs
Identifies cleavage strength deficiencies in metal adhesive systems before production
Delivers traceable cleavage strength test records for engineering and research submissions
Reduces design risk by verifying metal adhesive cleavage performance early in the approval cycle

Test Process

Sample Preparation

Metal-to-metal adhesive bond specimens prepared and cured per ASTM D 1062 requirements.

Cleavage Loading

Tensile cleavage force applied to bonded specimen at defined loading rate until bond failure.

Force Measurement

Maximum cleavage force recorded at adhesive bond failure for cleavage strength calculation.

Data Analysis & Reporting

Cleavage strength calculated and assessed against acceptance criteria for test compliance result.

Technical Specifications

Parameter	Details
Applicable Materials	Metal-to-metal adhesive bond joints and structural adhesive systems
Specimen Geometry	Defined metal substrate and bond area dimensions per ASTM D 1062
Loading Conditions	Defined tensile cleavage loading rate per ASTM D 1062 requirements
Measured Parameters	Maximum cleavage force and calculated cleavage strength per unit area
Measured Outputs	Maximum cleavage force, cleavage strength values, and test compliance result

Instrumentation Used for Testing

Universal testing machine with defined loading rate control
ASTM D 1062 cleavage test fixture for defined tensile cleavage loading
Precision load cell for maximum cleavage force measurement
Specimen conditioning chamber with temperature and humidity control
Surface preparation tools for defined metal substrate adhesion preparation
Data acquisition and test reporting system

Results and Deliverables

Cleavage force and cleavage strength data for all tested metal adhesive bond specimens
Calculated cleavage strength values per unit area per ASTM D 1062
Failure mode observations, including adhesive, cohesive, and substrate failure classification
Test compliance result assessed against the defined adhesive specification requirements
ASTM D 1062 test report

Why Choose Infinita Lab for ASTM D 1062?

Infinita Lab is a leading provider of ASTM D 1062 and streamlined material testing services, addressing the critical challenges faced by emerging businesses and established enterprises. With access to a vast network of over 2,000+ accredited partner labs across the United States, Infinita Lab ensures rapid, accurate, and cost-effective testing solutions. The company’s unique value proposition includes comprehensive project management, confidentiality assurance, and seamless communication through a Single Point of Contact (SPOC) model. By eliminating inefficiencies in traditional material testing workflows, Infinita Lab accelerates research and development (R&D) processes.

Looking for a trusted partner to achieve your research goals? Schedule a meeting with us, send us a request, or call us at (888) 878-3090 to learn more about our services and how we can support you. Request a Quote

Frequently Asked Questions

ASTM D1062 is an international standard that evaluates the cleavage strength of adhesive bonds on metal specimens. It measures the resistance of adhesive bonds to cleavage under controlled conditions and expresses the results in SI units.

Cleavage strength tests enable engineers to assess the durability of adhesive bonds subjected to peeling or separating forces. The tests ensure that bonded metal assemblies have structural integrity in applications such as aerospace and automobile components.

ASTM D1062 is often used for adhesive bonds between aluminum, steel, and other metal surfaces in structural bonding applications. It is important for areas where resistance to cleavage forces matters.

ASTM D1062 testing connects two metal pieces with adhesive. It applies a controlled force at one end and gradually pulls them apart to measure the adhesive joint's cleavage strength.

ASTM D1062 evaluates cleavage resistance under controlled laboratory conditions and may not represent real service environments where temperature changes, cyclic loading, corrosion, and environmental exposure affect adhesive bond durability.
