ASTM D6110: Charpy Impact Test for Plastics
ASTM D6110, The Charpy Impact Test, measures the energy absorbed by a plastic specimen while breaking under an impact load. A pendulum is used to break the plastic specimen. After a clean break, the energy loss of the pendulum due to the impact is recorded. Read more about ASTM D6110 Test for Charpy Impact Resistance of Notched Specimens of Plastics below.
TRUSTED BY
Precision-driven testing for dimensional accuracy and compliance
- Overview
- Scope, Applications, and Benefits
- Test Process
- Specifications
- Instrumentation
- Results and Deliverables
Overview
ASTM D6110 describes a standard method for determining the Charpy impact resistance of notched plastic specimens. The high-strain-rate test results directly provide a measure of the energy absorbed by a material during fracture, i.e., toughness.
A pendulum hammer strikes a notched specimen at a specified velocity; the energy absorbed at fracture is a measure of the material’s resistance to break under a shock force. ASTM D 6110 is widely used to assess the durability, resilience, and mechanical properties of plastic materials across a variety of applications.
Scope, Applications, and Benefits
Scope
ASTM D6110 evaluates the impact resistance of plastic materials using notched specimens. It assesses:
- Energy absorption during fracture
- Ductile versus brittle fracture behaviour
- Material toughness
- Temperature-dependent fracture performance
- Resistance to sudden mechanical shocks
- Reliability of plastic components
This method applies to rigid and semi-rigid plastic materials used in industrial and consumer applications.
Applications
- Automotive components (bumpers, dashboards, fuel systems)
- Aerospace plastic parts
- Consumer goods
- Construction materials
- Electrical enclosures
- Packaging components
- Research and development testing
Benefits
- Provides standardized impact resistance data
- Supports informed material selection
- Enhances product safety and durability
- Enables comparison between plastic grades
- Assists in quality control programs
- Helps predict real-world performance
Test Process
Specimen Preparation
Standard specimens are prepared with precise dimensions and a machined notch.
1Apparatus Setup & Impact Testing
The specimen is mounted and struck by a pendulum hammer at a controlled velocity.
2Energy Measurement & Correction
Absorbed fracture energy is recorded and corrected for friction losses.
3Data Normalization
Results are normalized based on specimen dimensions.
4Technical Specifications
| Parameter | Details |
|---|---|
| Applicable Materials | Rigid and semi-rigid plastics |
| Specimen Dimensions | 55 × 10 × 10 mm |
| Notch Type | Standard V-notch |
| Output Units | Joules (J) |
| Measured Outputs | Impact energy, impact resistance |
Instrumentation Used for Testing
- Charpy pendulum impact tester
- Precision specimen holder
- Calibrated energy scale
- Notching machine
- Temperature conditioning chamber (if required)
- Data recording system
Results and Deliverables
- Absorbed impact energy values (J)
- Impact resistance calculations
- Fracture mode classification (brittle/ductile)
- Comparative material performance reports
- Quality control documentation
- Test certificates
