ASTM F390 Sheet Resistance of Thin Metallic Films

ASTM F390 test method uses a collinear four probe array to assess the sheet resistance of metallic thin films. It is designed for rectangular metallic films with a thickness of 0.01 to 100 m created by material deposition and supported by insulating substrate. The values are stated in SI to be considered as standard.

Talk to an Expert

ASTM F390 Sheet Resistance of Thin Metallic Films

TRUSTED BY

Precision-driven testing for dimensional accuracy and compliance

Overview
Scope, Applications, and Benefits
Test Process
Specifications
Instrumentation
Results and Deliverables

Overview

ASTM F390 is a standardized test method intended to determine the ease of electrical current flow over the surface of thin films of metallic and semiconducting materials. It is primarily concerned with the sheet resistance, which is a measure of the in-plane lateral current flow in a film of uniform thickness.

The test method is used to determine the resistance per unit square of the film and is generally applied to the evaluation of conductive coatings, semiconductor layers, and thin metal deposits.

Scope, Applications, and Benefits

Scope

ASTM F390 relates to thin films of metallic and semiconducting materials, conductive coatings, and other uniform ultra-thin materials. The standard specifies a test method for determining lateral electrical resistance per square using a collinear four-probe configuration. This method is effective in reducing contact resistance, which makes it suitable for testing the electrical properties of thin films.

Applications

Semiconductor device manufacturing
Thin film electronics
Microelectronic circuits
Conductive coatings evaluation
Solar cell materials
Research and development of thin film materials
Quality control in coating processes
Failure analysis of conductive films

Benefits

Non-destructive electrical characterization
Accurate sheet resistance measurement
Eliminates contact resistance errors (four-probe method)
Suitable for very thin conductive layers
High repeatability and reliability
Supports process control in thin film fabrication
Provides standardized electrical testing procedure

Test Process

Specimen Preparation & Setup

Prepare a uniform film (≤10% thickness variation) and position the collinear four-probe array on the surface.

Current Application

Pass a measured direct current through the outer probes.

Voltage Measurement & Verification

Measure the voltage across the inner probes and verify equipment accuracy using a standard resistor circuit.

Calculation

Calculate sheet resistance from the measured current and voltage values.

Technical Specifications

Parameter	Details
Applicable Materials	Thin metallic and semiconducting films
Measurement Type	Lateral resistance per square
Thickness Requirement	Less than 10% thickness variation
Calculation Method	Average of ten resistance measurements
Output Units	Ohms per square

Instrumentation Used for Testing

Collinear four-point probe array
Constant current source
Voltmeter (high sensitivity)
Analog calibration circuit with standard resistor
Precision positioning stage
Data acquisition system

Results and Deliverables

Sheet resistance value
Average resistance calculation
Instrument calibration verification
Electrical performance evaluation report

Frequently Asked Questions

ASTM F390 is a standard test method for measuring sheet resistance of thin metallic films using a four-point probe technique.

It minimizes contact resistance effects, providing more accurate resistance measurement than two-point method.

The test measures flexural strength, core shear strength, facing stress, and load–deflection behavior to evaluate the structural performance of sandwich constructions.

The most important parameter is temperature, since the resistance of metals rises with increasing temperature. According to ASTM F390, the measurements are done in a temperature-controlled environment (usually 23°C), and the thermoelectric EMF is reduced to a minimum using current reversal methods.

The standard is intended for thin metal films evaporated on non-conductive (insulating) substrates, such as glass, ceramics, or polymers. If the substrate is conductive, the current will leak into the substrate, causing false low-resistance measurements.
