ASTM D 696 Test Method for Linear Thermal Expansion of Plastics

TRUSTED BY

Precision-driven testing for dimensional accuracy and compliance

Overview
Scope, Applications, and Benefits
Test Process
Specifications
Instrumentation
Results and Deliverables

Overview

ASTM D696 prescribes the standard test method for determining the linear thermal expansion characteristics of solid plastic materials subjected to controlled temperature changes. Linear thermal expansion describes the change in length of a plastic specimen per degree change in temperature and is an essential indicator of dimensional stability and structural performance.

This test method applies to homogeneous and reinforced plastics in molded, extruded, or fabricated forms. ASTM D696 provides reliable coefficient of linear thermal expansion data helpful in predicting material behavior in real-world situations where plastics are subjected to heating, cooling, or temperature fluctuations. Thermal expansion is significant to understand when plastics are assembled with metals, ceramics, or other materials with differing expansion rates.

Scope, Applications, and Benefits

Scope

ASTM D696 outlines procedures for measuring the coefficient of linear thermal expansion of plastics over a specified temperature range. It evaluates:

Change in length per unit length per degree of temperature change
Dimensional stability under thermal exposure
Thermal behavior of plastics during heating or cooling
Consistency of material expansion characteristics

The method applies to thermoplastics and thermosetting plastics in forms such as sheets, rods, plates, and fabricated components.

Applications

Automotive components and assemblies
Electronic and electrical housings
Construction and building materials
Aerospace and defence components
Packaging and structural plastic parts
Multi-material assemblies requiring thermal compatibility

Benefits

Provides accurate CLTE data for design and engineering
Helps prevent warping, cracking, and thermal stress buildup
Supports material selection for temperature-sensitive applications
Enables comparison of materials under standardized conditions
Enhances quality control and manufacturing consistency
Improves long-term reliability and dimensional accuracy

Test Process

Sample Preparation & Conditioning

Plastic specimens are cut or machined to precise dimensions and conditioned at standardized temperature and humidity to stabilize material behavior.

Specimen Placement

The specimen is positioned in a dilatometer or thermomechanical analyzer (TMA) under minimal mechanical stress.

Controlled Temperature Change

The specimen is gradually heated or cooled over a defined temperature range, typically starting near ambient temperature.

Dimensional Measurement & Data Recording

Length change is continuously measured as a function of temperature to calculate the coefficient of linear thermal expansion.

Technical Specifications

Parameter	Details
Applicable Materials	Thermoplastics and thermosetting plastics
Specimen Forms	Rods, bars, plates, sheets, and fabricated components
Typical Specimen Length	10–100 mm (instrument dependent)
Temperature Range	Defined test range based on the application
Measured Output	Coefficient of Linear Thermal Expansion (CLTE)
Units Reported	µm/m/°C or in./in./°F

Instrumentation Used for Testing

Dilatometer or thermomechanical analyzer (TMA)
Temperature-controlled heating and cooling system
Precision displacement measurement sensors
Specimen holders with low mechanical restraint
Data acquisition and thermal analysis software

Results and Deliverables

Coefficient of linear thermal expansion values
Dimensional change versus temperature curves
Assessment of thermal stability and compatibility
Data supporting material selection and design validation
Quality control documentation for manufacturing consistency
Comparative thermal expansion data for different plastics

Frequently Asked Questions

Plastics expand or contract more than metals when heated or cooled. Understanding this behavior prevents dimensional failures, warping, and stresses in product assemblies.

Thermoplastics, thermosets, reinforced composites, molded and extruded parts, and structural plastic components can all be evaluated using this method.

A dilatometer or thermomechanical analyzer (TMA) is typically used to measure precise dimensional change relative to temperature.
