ASTM D 3647 Plastic Pultruded Shapes

The ASTM D 3647 Standard Practice offers a systematic method for identifying reinforced plastic pultruded structures, classifying them following their unique composition, and promoting accurate communication and quality control in companies using these materials.

Talk to an Expert

TRUSTED BY

Precision-driven testing for dimensional accuracy and compliance

Overview
Scope, Applications, and Benefits
Test Process
Specifications
Instrumentation
Results and Deliverables

Overview

ASTM D3647 is a standard specification that covers pultruded plastic shapes produced from reinforced thermosetting resins. Pultrusion is a continuous manufacturing process in which reinforcing fibers such as glass fiber are impregnated with resin and pulled through a heated die to form structural profiles.

This standard establishes requirements for dimensions, mechanical properties, quality, and appearance of pultruded plastic structural shapes. It helps ensure that these composite materials meet consistent performance standards for structural and industrial applications.

Scope, Applications, and Benefits

Scope

ASTM D3647 defines the specifications and requirements for fiber-reinforced plastic pultruded structural shapes used in various engineering and industrial applications. It ensures product uniformity and reliable mechanical performance.

The standard also includes guidelines for material composition, dimensional tolerances, and inspection procedures to confirm compliance with quality requirements.

The scope includes:

Requirements for reinforced plastic pultruded shapes
Dimensional tolerance and profile specifications
Mechanical property requirements
Quality and appearance evaluation
Inspection and testing procedures

Applications

Structural components in construction
Industrial platforms and walkways
Electrical insulation structures
Chemical plant equipment
Marine and offshore structures

Benefits

High strength-to-weight ratio
Excellent corrosion resistance
Good electrical insulation properties
Low maintenance requirements
Long service life in harsh environments

Test Process

Material Preparation

Reinforcing fibers and thermosetting resins are prepared for the pultrusion manufacturing process.

Pultrusion Process

Resin-impregnated fibers are pulled through a heated die to form continuous structural profiles.

Cooling and Cutting

The formed profiles are cooled and cut into required lengths.

Inspection and Testing

Finished shapes are checked for dimensional accuracy, mechanical properties, and surface quality.

Technical Specifications

Parameter	Details
Material Type	Fiber-reinforced thermosetting plastic composites.
Reinforcement	Typically glass fiber or other reinforcing fibers.
Resin System	Polyester, vinyl ester, or epoxy resins.
Manufacturing Process	Continuous pultrusion through heated forming dies.
Profile Shapes	Channels, beams, rods, tubes, and structural profiles.
Dimensional Tolerance	Controlled according to specified profile dimensions.
Mechanical Properties	Includes tensile strength, flexural strength, and stiffness.
Surface Quality	Should be smooth and free from cracks, voids, or delamination
Environmental Resistance	High resistance to corrosion, moisture, and chemicals.

Instrumentation Used for Testing

Pultrusion Machine
Heated Forming Die
Universal Testing Machine (UTM)
Dimensional Measuring Tools (Calipers/Micrometers)
Optical Inspection Equipment

Results and Deliverables

Verification of pultruded shape dimensions
Mechanical property test results
Material composition confirmation
Surface quality inspection report
Complete ASTM D3647 compliance report

Why Choose Infinita Lab for ASTM D 3647?

Infinita Lab is a trusted USA-based testing laboratory offering ASTM D 3647 testing services across an extensive network of accredited facilities across the USA.

Infinita Lab is built to serve the full spectrum of modern testing needs—across industries, materials, and methodologies. Our advanced equipment and expert professionals deliver highly accurate and prompt test results, helping businesses achieve quality compliance and product reliability.

Looking for a trusted partner to achieve your research goals? Schedule a meeting with us, send us a request, or call us at (888) 878-3090 to learn more about our services and how we can support you. Request a Quote

Frequently Asked Questions

ASTM D3647 is a standard specification that defines the requirements for fiber-reinforced plastic pultruded structural shapes. It ensures that these composite products meet consistent quality and mechanical performance standards.

Pultruded shapes are composite structural profiles manufactured by pulling reinforcing fibers impregnated with resin through a heated die. This process creates strong and lightweight structural components.

They offer high strength, corrosion resistance, and lightweight performance, making them ideal for structural and industrial environments.

Industries such as construction, marine, electrical infrastructure, chemical processing, and transportation widely use pultruded plastic profiles.

Pultruded composites provide lower weight, corrosion resistance, and electrical insulation, reducing maintenance requirements in harsh environments.
