What Is Delamination and Adhesive Failure? Mechanisms and Detection
What Is Delamination?
Delamination is the separation of bonded layers within a laminated composite, coated substrate, or adhesively bonded assembly — occurring along the interface between plies, between coating and substrate, or within the adhesive bond line. It is one of the most prevalent and damaging failure modes in composite structures, coated products, and bonded assemblies across the aerospace, automotive, electronics, and glass industries.
What Is Adhesive Failure?
Adhesive failure is a specific type of bond failure in which separation occurs at the interface between the adhesive and one of the adherend surfaces — rather than within the adhesive bulk (cohesive failure) or within the adherend material (substrate failure). Adhesive failure at the adhesive-adherend interface indicates insufficient wetting, inadequate surface preparation, or fundamental incompatibility between the adhesive and substrate chemistry.
Delamination in Composite Materials
How Delamination Develops
In fibre-reinforced composite laminates, delamination initiates and propagates along the resin-rich layer between adjacent plies when:
- Interlaminar tensile stress exceeds the through-thickness tensile strength (from bending loads at free edges, holes, or ply drops)
- Interlaminar shear stress exceeds the interlaminar shear strength (ILSS) of the resin-fibre interface
- Impact damage causes internal delamination invisible from the surface (barely visible impact damage, BVID) — a primary structural concern in carbon fibre aerospace structures
- Fatigue cycling progressively grows existing delaminations under cyclic interlaminar loading
Detection of Composite Delamination
Scanning Acoustic Microscopy (SAM) — described in Blog 65 — is the primary non-destructive method for imaging delaminations in composite panels. Ultrasonic C-scan imaging maps delamination area and depth. Thermographic inspection (active thermography, lock-in thermography) detects delaminations from anomalies in heat diffusion through the laminate. For in-service inspection, phased array UT and pulse-echo UT detect delaminations from their normal incidence back-wall echo reduction.
Adhesive Failure in Glass and Coated Products
Delamination of Glass Laminates
Laminated safety glass consists of two or more glass sheets bonded with PVB (polyvinyl butyral) or EVA interlayers. Delamination between the glass and interlayer occurs from:
- Moisture ingress: Water penetrates the edge seal and plasticises the PVB, reducing its adhesion to the glass
- Thermal cycling: CTE mismatch stresses accumulate at the glass-PVB interface over repeated temperature cycles
- Incompatible surface chemistry: Silane coupling agent deficiency on the glass surface reduces PVB adhesion
- Impact damage: Severe impact separates the glass from the interlayer at the impact zone
Edge delamination in laminated glass is a significant aesthetic and structural defect — detected by visual inspection and characterised by microscopy and FTIR analysis of the delaminated interface.
Coating Delamination
Coating delamination from glass, metal, or polymer substrates results from:
- Hydrophobic substrate contamination (silicone, oil) — as described in Blog 62 (paint craters)
- Osmotic pressure from trapped moisture at the coating-substrate interface
- CTE mismatch stress from thermal cycling
- UV degradation of the adhesion-promoting primer layer
Testing and Characterisation of Delamination and Adhesive Failure
Peel Testing (ASTM D903, ASTM D1876)
Quantifies the force per unit width to separate bonded layers — providing adhesion strength data for coating and adhesive bond quality assurance.
Cross-Cut Adhesion Test (ASTM D3359)
Rapid qualitative screening for coating adhesion to substrate — used for quality control of painted and coated surfaces.
Pull-Off Adhesion Test (ASTM D4541)
Measures the tensile strength of the adhesive bond to the substrate — applicable to coatings on glass, metal, and concrete.
Scanning Acoustic Microscopy (SAM)
Non-destructive internal imaging of delaminations in composites, laminates, and bonded assemblies — described in Blog 65.
FTIR-ATR Analysis of Delaminated Surfaces
Chemical identification of delamination interface chemistry — detecting contamination, degradation products, or adhesion primer deficiency at the failure interface.
Why Choose Infinita Lab for Delamination and Adhesive Failure Analysis?
Infinita Lab provides delamination detection (SAM, UT, thermography), adhesion testing (peel, pull-off, cross-cut), and failure interface chemistry analysis (FTIR, SEM-EDS) through our nationwide accredited materials testing and failure analysis laboratory network.
