Rubber Impact Testing: ASTM D256, ISO 180 & ISO 179 GuideImpact testing is a fundamental mechanical evaluation method used to determine how materials behave under sudden, high-energy loading conditions. Across the North American market, industries such as aerospace, automotive, construction, and plastics rely on standardised impact tests—primarily Charpy and Izod methods—to assess material toughness, ductility-to-brittleness transitions, and fracture resistance. For manufacturers and R&D teams seeking accredited impact testing services at a US-based materials testing lab, Infinita Lab provides access to a nationwide network of specialised facilities.
What Is Impact Testing?
Impact testing measures the energy a material absorbs during fracture when subjected to a sudden blow. A pendulum hammer strikes a notched or un-notched specimen, and the energy absorbed during fracture is recorded. The two dominant methods in North America are the Charpy V-notch test (ASTM E23) and the Izod impact test (ASTM D256 for plastics, ASTM E23 for metals). These tests provide critical data on a material’s notch toughness, ductile-to-brittle transition temperature, and suitability for service in demanding environments.
Charpy vs. Izod Impact Testing
Charpy Impact Test
In the Charpy test, a standard V-notch specimen (typically 55 mm long, 10 mm square) is supported at both ends on an anvil and struck by a pendulum on the face opposite the notch. The energy absorbed during fracture indicates the material’s toughness. Tests are often conducted across a range of temperatures to establish the ductile-to-brittle transition curve—essential data for metals used in the aerospace and oil and gas industries.
Izod Impact Test
The Izod test positions the specimen vertically with the notch facing the pendulum. This configuration is widely used in the plastics and polymers industries to evaluate thermoplastics, thermosets, and reinforced composites in accordance with ASTM D256. The Izod method provides comparative toughness data that guides material selection for automotive components, consumer products, and packaging applications.
Key Industry Applications in North America
- Aerospace and Defence: Aircraft structural materials, landing gear alloys, and turbine components must demonstrate adequate impact resistance at both ambient and sub-zero temperatures. Charpy testing per ASTM E23 and AMS specifications ensures materials qualify for flight-critical applications where sudden loading and fatigue are constant concerns.
- Automotive Industry: Bumper systems, dashboard materials, door panels, and under-hood components undergo impact testing to meet FMVSS safety requirements and OEM performance specifications. Both metallic and polymer components are evaluated to ensure occupant protection during collision events.
- Construction and Structural Steel: Structural steel plates, beams, and welded connections require Charpy impact testing to confirm toughness at the minimum design temperature. Standards such as ASTM A370 and AWS D1.1 mandate impact testing for materials used in bridges, buildings, and infrastructure exposed to cold-weather service conditions.
- Plastics, Rubber, and Polymer Products: The packaging, consumer goods, and medical device industries use Izod and Charpy tests to evaluate the impact resistance of thermoplastics, elastomers, and composite materials. Testing per ASTM D256 and ISO 179 helps manufacturers select polymers that maintain toughness under real-world drop and impact scenarios.
Testing Standards Governing Impact Testing
The North American market primarily follows ASTM E23 (Charpy and Izod for metals), ASTM D256 (Izod for plastics), ASTM D6110 (Charpy for plastics), and ISO 179/ISO 180 for international equivalence. Additional specifications from AMS, AWS, and API further define testing requirements for aerospace, welding, and petroleum applications. Sub-sized specimens and alternative notch geometries are accommodated under these standards for materials with limited available thickness.
Factors Affecting Impact Test Results
Several variables influence impact test outcomes, including test temperature, specimen geometry and notch radius, loading rate, material microstructure, and heat treatment condition. Temperature is particularly critical—many metals and polymers exhibit dramatically reduced toughness at lower temperatures, which is why transition temperature testing is standard practice for safety-critical components in the energy, construction, and transportation sectors.
Why Choose Infinita Lab for Impact Testing?
Infinita Lab is a leading provider of Impact Testing and streamlined material testing services, addressing the critical challenges faced by emerging businesses and established enterprises. With access to a vast network of over 2,000+ accredited partner labs across the United States, Infinita Lab ensures rapid, accurate, and cost-effective testing solutions. The company’s unique value proposition includes comprehensive project management, confidentiality assurance, and seamless communication through a Single Point of Contact (SPOC) model. By eliminating inefficiencies in traditional material testing workflows, Infinita Lab accelerates research and development (R&D) processes.
Looking for a trusted partner to achieve your research goals? Schedule a meeting with us, send us a request, or call us at (888) 878-3090 to learn more about our services and how we can support you. Request a Quote
Frequently Asked Questions (FAQs)
What is the difference between Charpy and Izod impact tests? The Charpy test uses a horizontally supported specimen struck opposite the notch, while the Izod test uses a vertically clamped specimen struck on the notched side. Charpy is more common for metals, while Izod is widely used for plastics and polymers.
Why is temperature control important during impact testing? Many materials exhibit a ductile-to-brittle transition at specific temperatures. Testing across a temperature range reveals this transition point, which is critical for materials used in cold-climate construction, cryogenic equipment, and aerospace applications.
What ASTM standards apply to impact testing of plastics? ASTM D256 covers Izod pendulum impact testing of plastics, and ASTM D6110 covers Charpy impact testing of plastics. Both standards define specimen preparation, test conditions, and reporting requirements.
Can impact testing predict real-world product failure? Impact testing provides comparative toughness data and identifies brittle behavior under sudden loading. While it does not replicate every field condition, it is a reliable indicator of a material’s resistance to fracture under shock loads.
What sample sizes are required for Charpy impact testing? Standard Charpy V-notch specimens are 55 mm x 10 mm x 10 mm, with a 2 mm-deep, 0.25 mm-radius notch. Sub-sized specimens are permitted for thin materials, with results normalized to account for size differences.
