Advanced PEEK Material Testing: Engineering Properties and High-Performance Applications
Infinita Lab provides comprehensive testing for Polyether Ether Ketone (PEEK) to ensure compliance with aerospace, medical, and industrial standards.Polyether ether ketone (PEEK) is a semi-crystalline, high-performance thermoplastic renowned for its exceptional combination of mechanical strength, chemical resistance, thermal stability, and biocompatibility. PEEK maintains useful mechanical properties at temperatures up to 250°C continuously and 310°C short-term, making it the material of choice for demanding applications in the aerospace, oil and gas, automotive, medical devices, semiconductor, and electronics industries. For companies seeking PEEK testing at a US-based ASTM testing lab, Infinita Lab provides comprehensive polymer characterization through its accredited laboratory network.
Key PEEK Properties
Thermal Performance
PEEK has a glass transition temperature of 143°C and a melting point of 343°C, providing continuous service capability at 250°C. Its thermal stability (measured by TGA per ASTM E1131) shows decomposition onset above 500°C in nitrogen—exceptional among thermoplastics.
Mechanical Properties
Unfilled PEEK provides tensile strength of 100 MPa, flexural modulus of 4.1 GPa, and excellent fatigue resistance. Carbon fiber-reinforced PEEK grades achieve tensile strengths exceeding 200 MPa and modulus above 20 GPa, rivaling some metals.
Chemical and Radiation Resistance
PEEK resists nearly all organic solvents, acids, and bases at elevated temperatures. It withstands gamma radiation and steam sterilization, making it ideal for medical and nuclear applications.
Testing Standards for PEEK
ASTM D638 (tensile properties), ASTM D790 (flexural), ASTM D256 (Izod impact), ASTM D648 (heat deflection temperature), ASTM D3418 (DSC melting and crystallization), and ASTM E1131 (TGA composition) are standard tests for PEEK characterization and quality control.
Why Choose Infinita Lab for Plastics Testing?
At the core of this breadth is our network of 2,000+ accredited labs in the USA, offering access to over 10,000 test types. From advanced metrology (SEM, TEM, RBS, XPS) to mechanical, dielectric, environmental, and standardized ASTM/ISO testing, we give clients unmatched flexibility, specialization, and scale. You are not limited by geography, facility, or methodology—Infinita connects you to the right testing, every time.
Looking for a trusted partner to achieve your research goals? Schedule a meeting with us, send us a request, or call us at (888) 878-3090 to learn more about our services and how we can support you. Request a Quote
Frequently Asked Questions (FAQs)
What is PEEK? PEEK (polyether ether ketone) is a semi-crystalline high-performance thermoplastic with exceptional thermal stability (continuous use to 250°C), chemical resistance, mechanical strength, and biocompatibility.
What temperatures can PEEK withstand? PEEK provides continuous service at 250°C with short-term capability to 310°C. Its melting point is 343°C, and thermal decomposition begins above 500°C in an inert atmosphere.
What ASTM tests apply to PEEK? ASTM D638 (tensile), D790 (flexural), D256 (impact), D648 (HDT), D3418 (DSC), E1131 (TGA), and D1238 (melt flow) are standard characterization tests for PEEK materials.
What industries use PEEK? Aerospace (structural brackets, bushings), oil and gas (seals, backup rings), medical (spinal implants, surgical instruments), semiconductor (wafer handling), automotive (transmission components), and electronics (connectors) industries extensively use PEEK.
How does PEEK compare to the metals it replaces? PEEK offers 60–70% weight reduction versus steel, excellent fatigue resistance, chemical inertness, inherent flame resistance (UL 94 V-0), and elimination of corrosion—advantages that offset its higher raw material cost in demanding applications.
