Microelectronics Failure Analysis: A Complete Guide to Methods & Process
Microelectronics failure analysis conducted in an electronics testing laboratoryMicroelectronics failure analysis (FA) is a systematic investigation process that identifies the root cause of failures in integrated circuits, components, and assemblies. As device geometries shrink and circuit complexity increases, FA requires increasingly sophisticated analytical techniques and expertise. Effective failure analysis protects product quality, guides corrective actions, and prevents future failures across the semiconductor, consumer electronics, automotive, and aerospace industries. For companies seeking microelectronics failure analysis at a US-based testing lab, Infinita Lab provides advanced analytical services through its accredited laboratory network.
The Failure Analysis Process
Step 1: Failure Verification and History Review
The investigation begins with documenting the failure symptoms, reviewing application conditions, and reproducing the failure mode through electrical characterization. Comparing failed device behavior against specification and good device data establishes the specific failure signature.
Step 2: Non-Destructive Analysis
X-ray imaging reveals the integrity of internal wire bonds, solder joints, and die attaches. Scanning acoustic microscopy (SAM) detects delamination and voids in packaging. Curve tracing and parametric testing isolate the failing circuit or pin.
Step 3: Fault Isolation
Photoemission microscopy (PEM), thermal imaging (OBIRCH/TIVA), and laser-based techniques localize the defect site on the die to micrometer precision, guiding subsequent destructive analysis.
Step 4: Destructive Physical Analysis
Decapsulation (chemical or mechanical package removal), cross-sectioning, focused ion beam (FIB) milling, and SEM/TEM imaging reveal the physical defect. EDS and SIMS provide chemical composition at the failure site.
Common Failure Mechanisms
Common findings include ESD and electrical overstress damage, electromigration voids and hillocks, gate oxide breakdown, contamination-induced leakage, wire bond and solder joint failures, and moisture-driven corrosion of metallization in the semiconductor and electronics sectors.
Why Choose Infinita Lab for Microelectronics Failure Analysis?
Infinita Lab is a trusted USA-based testing laboratory offering Microelectronics Failure Analysis testing services across an extensive network of accredited facilities across the USA. Infinita Lab is built to serve the full spectrum of modern testing needs—across industries, materials, and methodologies. Our advanced equipment and expert professionals deliver highly accurate and prompt test results, helping businesses achieve quality compliance and product reliability.
Looking for a trusted partner to achieve your research goals? Schedule a meeting with us, send us a request, or call us at (888) 878-3090 to learn more about our services and how we can support you. Request a Quote
Frequently Asked Questions (FAQs)
What is microelectronics failure analysis? Microelectronics FA is the systematic investigation of failed electronic components to identify the physical defect, determine the failure mechanism, and establish the root cause to prevent recurrence.
What techniques are used for fault isolation? Photoemission microscopy (PEM), optical beam induced resistance change (OBIRCH), thermally induced voltage alteration (TIVA), and laser voltage probing localize defects on integrated circuits.
What is decapsulation? Decapsulation removes the plastic molding compound from an IC package to expose the die for optical, SEM, and probing analysis. Chemical (acid) and mechanical (laser, plasma) methods are used depending on the package type.
What standards govern microelectronics FA? JEDEC JESD22 series covers reliability tests, AEC-Q100 covers automotive IC qualification, MIL-STD-883 covers military device screening, and JEDEC JEP140 covers failure analysis procedures and reporting.
When is failure analysis needed? FA is needed for field returns investigation, production yield excursions, reliability test failures, customer complaints, design verification, and qualification testing to identify root causes and implement effective corrective actions.
