Procedure for Conducting Corrosion Tests: Step-by-Step Guide & Standards
Why Corrosion Testing Is Essential
Corrosion — the electrochemical or chemical degradation of metals and alloys in reaction with their environment — is responsible for an estimated $2.5 trillion in annual economic losses globally. For materials engineers and quality professionals, corrosion testing provides the empirical performance data needed to select corrosion-resistant materials, validate protective coatings, predict service life, and meet regulatory and specification requirements before products enter service.
A well-conducted corrosion test program follows standardized procedures — ensuring that results are reproducible, comparable across laboratories, and meaningful for engineering decisions across the oil and gas, automotive, marine, and infrastructure industries.
Categories of Corrosion Tests
Accelerated Laboratory Corrosion Tests
Salt Spray (Fog) Testing — ASTM B117 / ISO 9227 The most widely used accelerated corrosion test. Specimens are exposed to a continuous salt fog (5% NaCl solution at 35°C) in a sealed chamber for defined periods — typically 96, 240, 500, or 1,000 hours. Results include:
- Time to first rust spot (for galvanized and coated steel)
- Percentage of corroded area at defined intervals
- Creep from scribe (for coated specimens)
Salt spray is primarily a comparative and qualification test — not a direct predictor of atmospheric service life. A material or coating that passes 1,000 hours B117 does not necessarily last 10 years outdoors; but it performs better than one that fails at 500 hours.
Cyclic Corrosion Testing — SAE J2334, ASTM D5894, Volvo VCS 1027 Cyclic tests alternate between wet (high humidity), salt spray, dry (bake), and freeze exposures — creating more realistic corrosion conditions than constant-fog B117. Cyclic testing better predicts underfilm corrosion and coating delamination behavior observed in real-world outdoor service.
Prohesion / Modified Salt Spray — ASTM G85 Modified salt spray tests using dilute ammonium sulfate/sodium chloride solution (0.05% each) — better simulating industrial atmospheric corrosion. Prohesion cycling (wet-dry) produces more uniform coating performance ranking than standard B117 for many coating systems.
Electrochemical Corrosion Tests
Potentiodynamic Polarization — ASTM G5, G61 Measures corrosion current density, corrosion potential (E_corr), passivation potential, and pitting potential by scanning electrode potential while measuring current. Critical parameters:
- Corrosion rate: From Tafel slope extrapolation at E_corr
- Pitting potential (E_pit): Onset of localized attack — below this, the alloy is passive; above, pitting initiates
- Passive current density: Indicates passive film stability
Used for stainless steel, titanium, nickel alloy, and coated metal qualification.
Electrochemical Impedance Spectroscopy (EIS) — ASTM G106 Applies small AC perturbations across a range of frequencies and measures the impedance response — modeling the corrosion system as an equivalent electrical circuit. EIS quantifies:
- Coating barrier resistance (R_coat) — decrease over time indicates coating degradation
- Charge transfer resistance (R_ct) — governs active corrosion rate
- Diffusion impedance — tracks corrosion product layer formation
Specific Corrosion Mechanisms
Stress Corrosion Cracking (SCC) — ASTM G36, G44, G49 Specimens under defined constant load or constant displacement are exposed to specific corrosive environments (MgCl₂, H₂S/CO₂, seawater) and monitored for time-to-failure or crack growth rate.
Crevice Corrosion — ASTM G48, G78 Specimens with artificial crevices (PTFE washers at defined torque) are immersed in aggressive chloride solutions at elevated temperature. Crevice corrosion initiation and depth of attack are measured after defined exposure.
Intergranular Corrosion — ASTM A262 Tests for sensitized austenitic stainless steel — detecting grain boundary chromium depletion zones created by improper heat treatment that render the material susceptible to intergranular attack.
General Corrosion Test Procedure Best Practices
- Specimen preparation: Clean, degrease, and measure initial dimensions and mass to ±0.001 g; mark or tag for traceability
- Exposure setup: Orient specimens per standard (typically 15–30° from vertical in fog chambers); ensure no specimen-to-specimen contact
- Solution/environment preparation: Verify salt concentration, pH, and temperature before and during test
- Exposure duration: Follow standard or specification requirements; do not interrupt without documenting
- Post-exposure inspection: Photograph, measure corrosion product area, scrape and re-weigh for mass loss calculation
- Reporting: Document all deviations from standard conditions; report test temperature, duration, specimen dimensions, and results per applicable standard
Conclusion
Corrosion testing executed with rigorous procedural discipline — correct specimen preparation, calibrated equipment, standardized environments, and complete documentation — produces results that genuinely reflect material corrosion performance and can be reproduced and compared across laboratories. Organizations that invest in systematic corrosion testing programs prevent premature field failures, reduce warranty costs, and support evidence-based material selection and specification decisions.
Infinita Lab: Your Material Testing Partner
Contact Infinita Lab for corrosion testing with major benefits: end-to-end testing management, faster turnaround, and reduced administrative burden; confidence in accurate results and reduced stress in vendor coordination; enhanced reputation for product reliability and innovation; and engineers and R&D managers focused on core work rather than testing logistics.
Looking for a trusted partner to achieve your research goals? Schedule a meeting with us, send us a request, or call us at (888) 878-3090 to learn more about our services and how we can support you. Request a Quote
Frequently Asked Questions (FAQs)
Does passing 1,000 hours of ASTM B117 salt spray predict 10 years of outdoor service? No. ASTM B117 is a comparative and qualification test — not a direct service life predictor. Salt spray performance correlates roughly with outdoor durability rankings for similar coatings but the relationship between hours-in-chamber and years-outdoor depends heavily on geographic location, application, and coating type. Cyclic corrosion tests (SAE J2334) correlate better with real-world performance for automotive applications.
What is the difference between general corrosion and pitting corrosion? General (uniform) corrosion removes material relatively evenly across the entire exposed surface — predictable and designable by corrosion allowance. Pitting is localized — concentrated attack at discrete sites producing deep pits that penetrate the full wall thickness while most of the surface remains unattacked. Pitting is more dangerous because it causes perforation at much lower average metal loss and is harder to predict.
What specimen preparation is critical for accurate corrosion test results? Surface cleanliness is critical — oils, fingerprints, and manufacturing residues create artificial passive or active areas that compromise reproducibility. ASTM G1 specifies cleaning procedures: degreasing with acetone or alcohol, followed by acid pickling if oxide removal is needed, and final rinsing with deionized water. Initial mass and dimension measurements must be performed after cleaning.
How does electrochemical impedance spectroscopy (EIS) detect coating degradation? EIS measures coating barrier resistance (R_coat) — as water penetrates the coating, ionic conductivity increases and R_coat decreases. Tracking R_coat over time provides early warning of coating degradation — often before visible corrosion or blistering appears. EIS is more sensitive and information-rich than simple salt spray for tracking coating service life and mechanism.
What is the significance of the pitting potential (E_pit) measured by potentiodynamic polarization? Pitting potential defines the critical electrochemical threshold above which localized pitting initiates on a passive alloy surface. Service environments that hold the alloy at potentials above E_pit will cause pitting; environments below E_pit maintain passivity. E_pit measurement guides alloy selection, chloride concentration limits, and cathodic protection potential targets for corrosion control.
