ASTM E545 Neutron Radiography

Scope

ASTM E545 covers the determination of image quality in direct thermal neutron radiographic examination through the use of image quality indicator devices. The method assesses the quality of the radiographic image rather than directly evaluating a specific test object.

Key aspects of the test scope include:

• Image quality indicators – two reference devices are used: the beam purity indicator (BPI) and the sensitivity indicator (SI)
• Beam purity indicator (BPI) – characterizes the quality of the neutron beam, including measures related to scatter, gamma content, and the effective neutron content reaching the image plane
• Sensitivity indicator (SI) – contains a series of shims and absorbing gaps that establish the level of fine detail and small discontinuities the radiograph is able to resolve
• Direct thermal neutron radiography – the method applies to the direct radiographic technique using thermal neutrons (as opposed to indirect/transfer methods or other neutron energy ranges)
• Image quality categories – measurements from the BPI and SI are used to determine the quality level of the radiograph against defined categories
• Units – values stated in SI units are to be regarded as standard

Applications

• Aerospace component inspection – neutron radiography is widely used to inspect aerospace assemblies for trapped moisture, corrosion under structure, adhesive bond voids, and the presence of O-rings, sealants, and other organic materials inside metal parts; E545 verifies the image quality of these inspections
• Detection of hydrogenous materials in metals – locating organic materials, residues, lubricants, or moisture inside or behind metal components, which neutron radiography reveals where X-ray cannot
• Energetic and ordnance device inspection – examining the fill, voids, and assembly of pyrotechnic and explosive components, where neutron imaging of the energetic material is highly effective
• Investment casting and turbine blade inspection – detecting residual ceramic core material in cast turbine blades and similar components
• Corrosion and moisture detection – finding hidden corrosion products and trapped water in bonded and layered metal structures
• Image quality verification – providing the standardized basis for a neutron radiography facility to confirm and document that its radiographs meet the required quality level
• Process qualification – establishing that the neutron beam and imaging setup are capable of producing radiographs with the necessary purity and sensitivity

Benefits

• Verifies the radiograph is good enough to trust – by measuring beam purity and sensitivity on each radiograph, the method confirms the imaging conditions actually resolve the features of interest, rather than assuming they do
• Provides an objective, standardized quality measure – the BPI and SI give quantitative, reproducible indicators of image quality that mean the same thing across facilities and over time
• Supports a technique that complements X-ray – neutron radiography images light/hydrogenous materials in dense assemblies that X-ray struggles with; E545 underpins the reliability of these otherwise hard-to-obtain inspections
• Essential for high-consequence inspections – in aerospace and energetic-device applications, documented image quality is critical, and E545 provides the framework to establish it
• Enables consistent documentation – the standardized indicators allow image quality to be recorded and compared, supporting traceability and quality records for the inspection
