ASTM D3675 Surface Flammability Testing for Flexible Cellular Materials
A standard test procedure known as ASTM D 3675 is used to evaluate the surface flammability of flexible cellular materials when subjected to radiant heat energy. It enables comparison of the flammability of materials under particular test settings, but results might not apply to other test conditions since they may not be able to predict behaviour.
TRUSTED BY
Precision-driven testing for dimensional accuracy and compliance
- Overview
- Scope, Applications, and Benefits
- Test Process
- Specifications
- Instrumentation
- Results and Deliverables
Overview
ASTM D3675 is a standard test method used to evaluate the surface flammability of flexible cellular materials, such as foam plastics and elastomeric foams. The test measures how materials react when exposed to a controlled radiant heat source and flame.
The method helps determine the rate of flame spread and heat release from flexible foam materials. It is commonly used to compare the fire performance of materials used in furniture, insulation, and other polymer foam products.
Scope, Applications, and Benefits
Scope
ASTM D3675 describes a laboratory method for measuring the surface flammability behavior of flexible cellular materials exposed to radiant heat energy under controlled conditions.
The standard evaluates how materials ignite and how flames spread across the surface when subjected to a specific fire exposure scenario.
The scope includes:
Measurement of surface flammability of flexible cellular materials
Evaluation of flame spread characteristics
Use of radiant heat energy as a fire exposure source
Testing of foam materials and assemblies
Controlled laboratory fire response testing
Applications
Flexible polyurethane foam testing
Furniture cushioning materials
Polymer foam insulation materials
Automotive interior foam components
Building insulation and acoustic foams
Benefits
Evaluates fire behavior of flexible foam materials
Helps compare flammability performance of products
Supports fire safety evaluation in materials
Provides standardized fire testing conditions
Assists manufacturers in improving fire resistance
Test Process
Specimen Preparation
Foam specimens of specified dimensions are prepared and conditioned before testing.
1Radiant Heat Exposure
The specimen is placed in front of a radiant heat panel and exposed to controlled heat energy.
2Flame Ignition and Spread
A pilot flame ignites the material, and the flame spread across the surface is observed.
3Flammability Measurement
The rate of flame spread and heat release are recorded to calculate the Radiant Panel Index.
4Technical Specifications
| Parameter | Details |
|---|---|
| Test Principle | Measurement of surface flammability under radiant heat exposure. |
| Heat Source | Radiant panel providing controlled heat energy. |
| Specimen Orientation | Specimen positioned at an inclined angle relative to the heat source. |
| Ignition Source | Small pilot burner used to ignite the specimen surface. |
| Measured Parameter | Flame spread rate and heat release characteristics. |
| Index Calculation | Results expressed as a Radiant Panel Index (RPI) value. |
| Testing Conditions | Conducted under controlled laboratory fire exposure conditions. |
Instrumentation Used for Testing
Radiant Panel Flammability Tester
Pilot Burner / Ignition System
Specimen Holder Assembly
Heat Flux Measurement System
Data Recording System
Results and Deliverables
Radiant Panel Index (RPI) value
Flame spread behavior data
Heat release analysis
Flammability performance report
Complete ASTM D3675 laboratory test report
Why Choose Infinita Lab for ASTM D 3675?
At the core of this breadth is our network of 2,000+ accredited labs in the USA, offering access to over 10,000 test types. From advanced metrology (SEM, TEM, RBS, XPS) to mechanical, dielectric, environmental, and standardized ASTM/ISO testing, we give clients unmatched flexibility, specialization, and scale. You’re not limited by geography, facility, or methodology—Infinita connects you to the right testing, every time.
Looking for a trusted partner to achieve your research goals? Schedule a meeting with us, send us a request, or call us at (888) 878-3090 to learn more about our services and how we can support you. Request a Quote
Frequently Asked Questions
ASTM D3675 is a fire test method used to determine the surface flammability of flexible cellular materials exposed to a radiant heat source. It helps measure flame spread characteristics under controlled conditions.
The Radiant Panel Index is a value calculated from the flame spread rate and heat release during testing. It provides a numerical indication of the material's flammability performance.
The specimen is placed in an inclined position in front of a radiant heat panel so that ignition occurs at the upper edge and the flame spreads downward.
The test measures fire response under controlled conditions but does not fully predict real-life fire hazards, since many environmental factors affect actual fire behavior.
Flame spread can depend on material composition, density, thickness, mounting method, and heat exposure conditions.
