ASTM D7298 Legibility Testing for Pavement Markings by Polarizing Filter
ASTM D7298 test method defines a standard technique for assessing the comparative legibility of printed matter under consistent and controlled light conditions using a specialized instrument. The printed matter to be tested are the package labeling, printed inserts, and carton graphics. The test method aids in determining the impact of layout, typeface, type size, color, and background on printed matter legibility.
TRUSTED BY
Precision-driven testing for dimensional accuracy and compliance
- Overview
- Scope, Applications, and Benefits
- Test Process
- Specifications
- Instrumentation
- Results and Deliverables
Overview
ASTM D7298 describes a test method for measuring the comparative legibility of printed or displayed text and graphics using polarizing filter instrumentation. Legibility is a critical optical property for signage, displays, labels, and printed documents where information must be clearly discernable under varying lighting conditions, including ambient glare.
The method provides a quantitative, instrument-based measure of legibility that reduces the subjectivity of visual inspection and supports objective comparison of display or print technologies.
Scope, Applications, and Benefits
Scope
ASTM D7298 applies to printed text, LCD/LED displays, and optically readable surfaces and measures:
- Comparative legibility index under defined illumination
- Legibility under direct and polarized light conditions
- Contrast ratio between text and background
- Glare contribution to legibility degradation
Applications
- Signage and wayfinding display legibility qualification
- Pharmaceutical label and medical device display legibility
- Automotive instrument cluster and HUD display assessment
- Industrial safety sign clarity verification
- Comparative testing of printing technologies and substrates
Benefits
- Provides objective, instrument-based legibility measurement
- Simulates adverse lighting conditions including specular glare
- Enables side-by-side comparison of competing display or print technologies
- Supports safety signage compliance documentation
- Reproducible, standardized measurement across laboratories
Test Process
Instrument Setup
The polarizing filter photometer is aligned and calibrated; illumination geometry is set per the standard specification.
1Baseline Measurement
Luminance or reflectance of the background and character areas is measured without polarizing filters to establish baseline contrast.
2Polarized Measurement
Measurements are repeated with a polarizing filter; legibility index is derived from filtered vs. unfiltered data.
3Comparative Reporting
Legibility indices are compared and ranked, with results reported alongside geometry and illumination conditions.
4Technical Specifications
| Parameter | Details |
|---|---|
| Standard | ASTM D7298 |
| Test Principle | Photometric contrast measurement with and without polarizing filter |
| Applicable Materials | Printed text, labels, displays, and signage surfaces |
| Measurement | Luminance or reflectance ratio (contrast) |
| Measured Output | Comparative legibility index |
| Illumination | Defined geometry per standard |
Instrumentation Used for Testing
- Polarizing filter photometer or spectrophotometer
- Defined illumination source (D65 or specified)
- Test sample holder with controlled viewing angle
- Reference legibility standards for instrument verification
- Data recording system
Results and Deliverables
- Legibility index values for each tested specimen
- Contrast ratio under ambient and polarized conditions
- Ranked comparison of competing print or display options
- Effect of surface finish or coating on legibility
- Test report with measurement geometry and conditions
