Ignition Loss (LOI) of Cured Reinforced Resins: Method & Applications
Precision ignition loss testing of reinforced resins at Infinita LabIgnition loss testing determines the resin (organic) content of cured fiber-reinforced plastic (FRP) composites by burning away the polymer matrix in a high-temperature furnace and measuring the weight of the remaining inorganic reinforcement. This straightforward yet essential test provides critical quality-control data to verify fiber-to-resin ratios in the composites, automotive, aerospace, marine, and construction industries. For manufacturers seeking composite ignition loss testing at a US-based ASTM testing lab, Infinita Lab provides comprehensive composite characterization through its accredited laboratory network.
How Ignition Loss Testing Works
A weighed specimen of cured composite is placed in a pre-weighed crucible and heated in a muffle furnace at 565°C (1050°F) for ASTM D2584 or 625°C for ASTM D3171 until all organic material is combusted. The crucible is cooled and reweighed. The weight loss represents the resin (plus any organic additives) content, while the residue represents the glass fiber, mineral filler, or other inorganic reinforcement content.
Key Testing Standards
ASTM D2584 – Ignition Loss of Cured Reinforced Resins
ASTM D2584 is the most widely used standard, specifying ignition at 565± 28°C until constant weight is achieved. It applies to glass fiber-reinforced polyester, vinyl ester, and epoxy composites and provides a rapid, accurate determination of resin content.
ASTM D3171 – Constituent Content of Composite Materials
ASTM D3171 covers both ignition (Method I) and acid digestion (Method II) for determining fiber, resin, and void content. It provides more comprehensive compositional data and applies to a broader range of reinforcement types, including carbon fiber.
Why Resin Content Matters
Fiber-to-resin ratio directly affects composite mechanical properties, weight, cost, and processability. Too much resin reduces stiffness and strength; too little causes dry spots, porosity, and poor interlaminar bonding. Manufacturing quality control requires verifying that the actual resin content matches the design specification.
Why Choose Infinita Lab for Composite Testing?
At the core of this breadth is our network of 2,000+ accredited labs in the USA, offering access to over 10,000 test types. From advanced metrology (SEM, TEM, RBS, XPS) to mechanical, dielectric, environmental, and standardized ASTM/ISO testing, we give clients unmatched flexibility, specialization, and scale. You are not limited by geography, facility, or methodology—Infinita connects you to the right testing, every time.
Looking for a trusted partner to achieve your research goals? Schedule a meeting with us, send us a request, or call us at (888) 878-3090 to learn more about our services and how we can support you. Request a Quote
Frequently Asked Questions (FAQs)
What is ignition loss testing? Ignition loss testing burns away the organic resin matrix of a composite in a high-temperature furnace, leaving the inorganic reinforcement residue. The weight difference determines resin content as a percentage of total composite weight.
What ASTM standard covers the ignition loss of composites? ASTM D2584 is the primary standard for ignition loss of cured reinforced resins. ASTM D3171 provides a more comprehensive method covering fiber content, resin content, and void volume in composite materials.
What temperature is used for ignition loss testing? ASTM D2584 specifies 565± 28°C (1050± 50°F). This temperature completely combusts organic resins while leaving glass fiber and mineral fillers intact. Carbon fiber composites require acid digestion (ASTM D3171 Method II) instead.
Can ignition loss testing be used for carbon fiber composites? No, carbon fibers also burn at elevated temperatures. Carbon fiber composites require acid digestion per ASTM D3171 Method II, which dissolves the resin matrix chemically without affecting the carbon fiber reinforcement.
What is a typical resin content for FRP composites? Resin content typically ranges from 25–45% by weight for structural FRP composites. Hand lay-up produces higher resin content (35–45%), while filament winding and RTM achieve lower, more controlled resin percentages (25–35%).
